Frame
SCREE 6061 Alloy Stealth Evo, Updated Zero Suspension System, 130mm travel, Forward Geometry, internal removable battery, Boost 12x148mm rear axle, UDH, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, exclusive plastic motor covers.
Sizes
S: 380mm / M: 410mm / ML: 435mm / L: 460mm / XL: 490mm
Rear shock
Shock settings
LCM compression, LRM rebound, CMF, 0.8 volume spacer
-
Fork
Headset
Acros custom ZS56/ZS56, 1-1/8", 1.5" head tube, Internal cable routing, sealing plugs without blocklock
-
Stem
Handlebar
Onoff S6 1.0 7050 alloy, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 38mm rise.
-
Grips
Seatpost
X-Fusion Manic diameter 31.6mm,1X Remote lever, S size: 361x125mm, M size: 425x150mm, ML size: 469x170mm, L size: 521x190mm, XL size: 531x200
-
Saddle
| Cadre | SCREE 6061 Alloy Stealth Evo, suspension Zero, 130 mm, batterie interne amovible, Boost 12x148 mm, câblerie interne |
| Fourche | Fox 36 29 Float Rhythm, 150mm, tapered steerer tube, Boost 15x110mm Kabolt axle, 44mm offset. Settings: GRIP Sweep-Adjust |
| Amortisseur | Fox Float Rhythm EVOL 165x45mm. Settings: Settings: 2-position compression (Open/Firm), rebound, air preload. Trunnion top mount, 30x8mm bottom bushings |
| Jeu de direction | Acros ZS56/ZS56, câblerie interne |
| Moteur | Bosch Performance Line CX Smart System, 25 km/h |
| Batterie | Bosch Powertube 800Wh |
| Écran | Bosch Kiox 400C / Mini Remote |
| Dérailleur arrière | Sram 70 Eagle T-Type, 12 vitesses |
| Manettes | Sram Trigger 70, 12s, T-Type Actuation |
| Pédalier | Sram Eagle 34T T-Type, direct mount, steel, CL55 |
| Cassette | Sram XS-1270, 10-52T, 12s |
| Freins | Sram DB6, tool reach adjust, lever pivot bushings/
Sram DB6, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads |
| Roues | e*thirteen Grappler Core, IW30 Hookless, 6066 Welded Aluminum, 30mm internal width, tubeless ready, 28 spokes |
| Pneus | Maxxis Dissector 29x2.6, tubeless ready, tubeless ready, 3C MaxxTerra compoundm EXO+ protection, 60TPI, folding bead |
| Guidon |
Onoff S6 1.0 7050 alloy, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 38mm rise. |
| Potence | Onoff S6 30mm 0º, 6061 forged alloy + CNC, 31.8mm barbore |
| Tige de selle | X-Fusion Manic diameter 31.6mm,1X Remote lever, S size: 361x125mm, M size: 425x150mm, ML size: 469x170mm, L size: 521x190mm, XL size: 531x200 |
| Selle | Ergon SMC10 Gel |
| Poids | 25.6 kg |
| Coloris | Flame Red |
